Tap, Die & Drill Sets; Minimum Tap Thread Size: 4-40; Maximum Tap Thread Size: 1/8-27; Minimum Die Thread Size: 4-40; Maximum Die Thread Size: 1/8"-27; Minimum Drill Size: 0; Maximum Drill Size: 0; Die Shape: Hex; Adjustable Die: No
Item #: 56530108
Brand: Milwaukee Tool
Model #: 49-22-5604
Product Specifications
| Minimum Tap Thread Size | 4-40 |
| Maximum Tap Thread Size | 1/8-27 |
| Minimum Die Thread Size | 4-40 |
| Maximum Die Thread Size | 1/8"-27 |
| Minimum Drill Size | 0 |
| Maximum Drill Size | 0 |
| Die Shape | Hex |
| Adjustable Die | No |
| Number Of Dies | 17 |
| Number Of Drills | 0 |
| Number Of Taps | 17 |
| Thread Sizes Included | 4-40 NC,6-32 NC,8-32 NC,10-24 NC,10-32 NF,12-24 NC,1/4"-20 NC,1/4"-28 NF, 5/16"-18 NC,5/16"-24 NF, 3/8"-16 NC,3/8"-24 NF,7/16"-14 NC ,7/16"-20 NF,1/2"-13 NC,1/2"-20 NF,1/8"-27 NPT |
| Drill Sizes Included | 0 |
| Tap Material | Carbon Steel |
| Die Material | Steel |
| Drill Material | High Speed Steel |
| Tap Finish | Black |
| Drill Finish | Black |
| Die Hex Size | 1 in |
| Chamfer | Plug; Taper |
| Thread Standard | NPT; UNC; UNF |
| Case Type | Plastic Case |
| Includes | (1) 4-40 NC Plug Tap, (1) 6-32 NC Plug Tap, (1) 8-32 NC Plug Tap, (1) 10-24 NC Plug Tap, (1) 10-32 NF Plug Tap, (1) 12-24 NC Plug Tap, (1) 1/4"-20 NC Plug Tap, (1) 1/4"-28 NF Plug Tap, (1) 5/16"-18 NC Plug Tap, (1) 5/16"-24 NF Plug Tap, (1) 3/8"-16 NC Plug Tap, (1) 3/8"-24 NF Plug Tap, (1) 7/16"-14 NC Plug Tap, (1) 7/16"-20 NF Plug Tap, (1) 1/2"-13 NC Plug Tap, (1) 1/2"-20 NF Plug Tap, (1) 1/8"-27 NPT Taper Tap, (1) 4-40 NC Hex Die, (1) 6-32 NC Hex Die, (1) 8-32 NC Hex Die, (1) 10-24 NC Hex Die, (1) 10-32 NF Hex Die, (1) 12-24 NC Hex Die, (1) 1/4"-20 NC Hex Die, (1) 1/4"-28 NF Hex Die, (1) 5/16"-18 NC Hex Die, (1) 5/16"-24 NF Hex Die, (1) 3/8"-16 NC Hex Die, (1) 3/8"-24 NF Hex Die, (1) 7/16"-14 NC Hex Die, (1) 7/16"-20 NF Hex Die, (1) 1/2"-13 NC Hex Die, (1) 1/2"-20 NF Hex Die, (1) 1/8"-27 NPT Hex Die, (1) 8-44 SAE Thread Gauge, (1) Sliding T-Handle, (1) Tap Collet, (1) Hex-LOK 2-IN-1 Handle |
| Number Of Pieces | 38 |
| UNSPSC Code | 23241600 |
| Minimum Tap Thread Size | 4-40 |
| Maximum Tap Thread Size | 1/8-27 |
| Minimum Die Thread Size | 4-40 |
| Maximum Die Thread Size | 1/8"-27 |
| Minimum Drill Size | 0 |
| Maximum Drill Size | 0 |
| Die Shape | Hex |
| Adjustable Die | No |
| Number Of Dies | 17 |
| Number Of Drills | 0 |
| Number Of Taps | 17 |
| Thread Sizes Included | 4-40 NC,6-32 NC,8-32 NC,10-24 NC,10-32 NF,12-24 NC,1/4"-20 NC,1/4"-28 NF, 5/16"-18 NC,5/16"-24 NF, 3/8"-16 NC,3/8"-24 NF,7/16"-14 NC ,7/16"-20 NF,1/2"-13 NC,1/2"-20 NF,1/8"-27 NPT |
| Drill Sizes Included | 0 |
| Tap Material | Carbon Steel |
| Die Material | Steel |
| Drill Material | High Speed Steel |
| Tap Finish | Black |
| Drill Finish | Black |
| Die Hex Size | 1 in |
| Chamfer | Plug; Taper |
| Thread Standard | NPT; UNC; UNF |
| Case Type | Plastic Case |
| Includes | (1) 4-40 NC Plug Tap, (1) 6-32 NC Plug Tap, (1) 8-32 NC Plug Tap, (1) 10-24 NC Plug Tap, (1) 10-32 NF Plug Tap, (1) 12-24 NC Plug Tap, (1) 1/4"-20 NC Plug Tap, (1) 1/4"-28 NF Plug Tap, (1) 5/16"-18 NC Plug Tap, (1) 5/16"-24 NF Plug Tap, (1) 3/8"-16 NC Plug Tap, (1) 3/8"-24 NF Plug Tap, (1) 7/16"-14 NC Plug Tap, (1) 7/16"-20 NF Plug Tap, (1) 1/2"-13 NC Plug Tap, (1) 1/2"-20 NF Plug Tap, (1) 1/8"-27 NPT Taper Tap, (1) 4-40 NC Hex Die, (1) 6-32 NC Hex Die, (1) 8-32 NC Hex Die, (1) 10-24 NC Hex Die, (1) 10-32 NF Hex Die, (1) 12-24 NC Hex Die, (1) 1/4"-20 NC Hex Die, (1) 1/4"-28 NF Hex Die, (1) 5/16"-18 NC Hex Die, (1) 5/16"-24 NF Hex Die, (1) 3/8"-16 NC Hex Die, (1) 3/8"-24 NF Hex Die, (1) 7/16"-14 NC Hex Die, (1) 7/16"-20 NF Hex Die, (1) 1/2"-13 NC Hex Die, (1) 1/2"-20 NF Hex Die, (1) 1/8"-27 NPT Hex Die, (1) 8-44 SAE Thread Gauge, (1) Sliding T-Handle, (1) Tap Collet, (1) Hex-LOK 2-IN-1 Handle |
| Number Of Pieces | 38 |
| UNSPSC Code | 23241600 |
| MSC Part # | 56530108 |
| Mfr Part # | 49-22-5604 |
| Country of Origin Country of Origin is subject to change | China |
