Kennametal - Right Hand Cut, KM32 Modular Connection, Adapter/Mount Lathe Modular Clamping Unit - 30mm Square Shank Diam, 3.982" OAL, Through Coolant, Series CLRR VDI Right Angle
Item #: 09731415
Brand: Kennametal
Model #: 1324688
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Clamping Unit Type | Adapter/Mount |
| Series Code | CLRR VDI Right Angle |
| Connection Size | KM32 |
| Cutting Direction | Right Hand |
| Shank Diameter (mm) | 30.00 |
| Shank Diameter (Decimal Inch) | 1.1810 |
| Through Coolant | Yes |
| Head Height (mm) | 80.01 |
| Head Height (Decimal Inch) | 3.1500 |
| Overall Length (mm) | 101.14 |
| Overall Length (Decimal Inch) | 3.9820 |
| Head Length (Decimal Inch) | 1.8120 |
| Head Length (mm) | 46.02 |
| Shank Length (mm) | 55.12 |
| Shank Length (Decimal Inch) | 2.1700 |
