Heli-Coil - Single Insert, 5/16-18 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 6-5/8 Free Coils, 15/32 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 09650649
Brand: Heli-Coil
Model #: A3585-5CNW469
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 5/16-18 |
Overall Insert Length (Decimal Inch) | 0.4690 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3800 |
Maximum Outside Diameter (Decimal Inch) | 0.4000 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 6-5/8 |
Maximum Locking Torque (In/Lb) | 60 |
Minimum Break Away Torque (In/Lb) | 7.50 |
Thread Standard | UNC |
Material Grade | 304 |
