Vectrax - 9 x 14-9/16" Max Capacity, Manual Step Pulley Horizontal Bandsaw - 82, 127, 186 & 300 SFPM Blade Speed, 220 Volts, 2 hp, 3 Phase
Item #: 09518895
Brand: Vectrax
Model #: MH-916JR-3
Exact Tooling IR#: 04
Features and Benefits
Manual bandsaws are controlled by an operator. They manually load the material into the saw, measure lengths to cut and adjust stops.
Step pulleys are driven by a belt system that is manually changed to achieve a specific speed. These pulleys commonly feature 3 to 4 fixed speeds.
Three-phase refers to three individual lines (coils) that connect to and run voltage through the motor. Each line alternates in a sequence as it reaches its voltage peak. They provide a more stable flow of voltage and more horsepower to the equipment.
| Product Specifications | |
|---|---|
| Machine Style | Manual |
| Drive Type | Step Pulley |
| Maximum Capacity (Rectangular) (Inch) | 9 x 14-9/16 |
| Maximum Capacity (Rounds) (Inch) | 9 |
| Phase | 3 |
| Voltage | 220 |
| Coolant System | Yes |
| Blade Width (mm) | 26.92 |
| Blade Width (Decimal Inch) | 1.0000 |
| Blade Speeds (SFPM) | 82 , 127 , 186 , 300 |
| Blade Length (Inch) | 132 |
| Blade Length (Decimal Inch) | 132.0000 |
| Blade Length (mm) | 3352.80 |
| Blade Thickness (mm) | 0.89 |
| Blade Thickness (Decimal Inch) | 0.0350 |
| Blade Guide Type | Carbide |
| Blade Speeds (SFPM) | 82 , 127 , 186 , 300 |
| Horsepower (HP) | 2.00 |
| Base Width (mm) | 787.40 |
| Base Width (Inch) | 31 |
| Base Depth (mm) | 1701.80 |
| Base Depth (Inch) | 67 |
