Brand: Value Collection / Part #: 890-9988 ULT-FAGOR

Brand: Value Collection / Part #: 890-9988 ULT-FAGOR


Item #: 71485916
Brand: Value Collection
Model #: 890-9988 ULT-FAGOR

Product Specifications

Minimum Spindle to Table Distance (Decimal Inch) 7.0000
Minimum Spindle to Table Distance (Inch) 7
Maximum Spindle to Table Distance (Inch) 26.0000
Maximum Spindle to Table Distance (Decimal Inch) 26.0000
Minimum Spindle Speed 70 RPM
Maximum Spindle Speed 4200 RPM
Forward Head Tilt (Degrees) 45
Phase Three
Backward Head Tilt (Degrees) 45
Left-Hand Head Tilt (Degrees) 90
Left-hand Head Tilt 90.0 ?
Right-Hand Head Tilt (Degrees) 90
Right-hand Head Tilt 90.0 ?
Cross Travel (Decimal Inch) 16.5000
Cross Travel 16.5 in
Longitudinal Travel 39.0 in
Longitudinal Travel (Decimal Inch) 39.0000
Knee Travel (Decimal Inch) 17.7500
Knee Travel 17.75 in
Quill Diameter (Inch) 3-3/8
Quill Diameter (Decimal Inch) 3.3750
Horsepower 3.00
Voltage 220V
Table Length (Inch) 54
Table Width (Inch) 10
Ram Turret Swivel (Degrees) 360
Ram Travel Length (Decimal Inch) 18.0000
Ram Travel Length (Inch) 18
Spindle Speed Control Variable Speed Pulley
Spindle Taper Size R8
Spindle Travel Length (Decimal Inch) 5.0000
Spindle Travel Length (Inch) 5
Number Of T-slots 3
Overall Height (Decimal Inch) 88.0000
Overall Height (Inch) 88
Overall Length (Inch) 66
Overall Length (Decimal Inch) 66.0000
Overall Depth (Inch) 72
Overall Depth (Inch) 72.0000
$16,343.04
