Titan USA - Spiral Point Taps; Thread Size (mm): M3x0.50 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 6H ; Thread Limit: D3 ; Finish/Coating: Uncoated
Item #: 07974066
Brand: Titan USA
Model #: TT93217
Product Specifications
Spiral Point Taps; Thread Size (mm): M3x0.50 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 6H ; Thread Limit: D3 ; Finish/Coating: Uncoated
Thread Size (mm) | M3x0.50 |
Number of Flutes | 2 |
Chamfer | Plug |
Class of Fit | 6H |
Thread Limit | D3 |
Finish/Coating | Uncoated |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 1.9375 |
Overall Length (Inch) | 1-15/16 |
Thread Standard | Metric Coarse |
Thread Length (Decimal Inch) | 0.6250 |
Thread Length (Inch) | 5/8 |
Series/List | 780 |
Shank Diameter (Decimal Inch) | 0.1410 |
Square Length (Inch) | 3/16 |
Square Size (Decimal Inch) | 0.1100 |
Square Size (mm) | 2.80 |
