Titan USA - Spiral Point Taps; Thread Size (Inch): #8-36 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 3B ; Thread Limit: H1 ; Finish/Coating: Uncoated
Item #: 07973902
Brand: Titan USA
Model #: TT91032
Product Specifications
Spiral Point Taps; Thread Size (Inch): #8-36 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 3B ; Thread Limit: H1 ; Finish/Coating: Uncoated
Thread Size (Inch) | #8-36 |
Number of Flutes | 2 |
Chamfer | Plug |
Class of Fit | 3B |
Thread Limit | H1 |
Finish/Coating | Uncoated |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 2.1250 |
Overall Length (Inch) | 2-1/8 |
Thread Standard | UNF |
Thread Length (Decimal Inch) | 0.7500 |
Thread Length (Inch) | 3/4 |
Series/List | 750 |
Shank Diameter (Decimal Inch) | 0.1680 |
Square Length (Inch) | 1/4 |
Square Size (Decimal Inch) | 0.1310 |
