Titan USA - Spiral Point Taps; Thread Size (Inch): #6-40 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H2 ; Finish/Coating: Steam Oxide
Item #: 07973829
Brand: Titan USA
Model #: TT91027S
Product Specifications
Spiral Point Taps; Thread Size (Inch): #6-40 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H2 ; Finish/Coating: Steam Oxide
Thread Size (Inch) | #6-40 |
Number of Flutes | 2 |
Chamfer | Plug |
Class of Fit | 2B/3B |
Thread Limit | H2 |
Finish/Coating | Steam Oxide |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 2.0000 |
Overall Length (Inch) | 2 |
Thread Standard | UNF |
Thread Length (Decimal Inch) | 0.6875 |
Thread Length (Inch) | 11/16 |
Series/List | 751 |
Shank Diameter (Decimal Inch) | 0.1410 |
Square Length (Inch) | 3/16 |
Square Size (Decimal Inch) | 0.1100 |
Square Size (mm) | 2.80 |
