Titan USA - Spiral Point Taps; Thread Size (Inch): #10-24 ; Number of Flutes: 2 ; Chamfer: Plug ; Thread Limit: H7 ; Finish/Coating: Uncoated ; Material: High Speed Steel
Item #: 07973712
Brand: Titan USA
Model #: TT91037
Product Specifications
Spiral Point Taps; Thread Size (Inch): #10-24 ; Number of Flutes: 2 ; Chamfer: Plug ; Thread Limit: H7 ; Finish/Coating: Uncoated ; Material: High Speed Steel
| Thread Size (Inch) | #10-24 |
| Number of Flutes | 2 |
| Chamfer | Plug |
| Thread Limit | H7 |
| Finish/Coating | Uncoated |
| Material | High Speed Steel |
| Through Coolant | NonThrough Coolant |
| Thread Direction | Right Hand |
| Overall Length (Decimal Inch) | 2.3750 |
| Overall Length (Inch) | 2-3/8 |
| Thread Standard | UNC |
| Thread Length (Decimal Inch) | 0.8750 |
| Thread Length (Inch) | 7/8 |
| Series/List | 750 |
| Shank Diameter (Decimal Inch) | 0.1940 |
| Square Length (Inch) | 1/4 |
| Square Size (Decimal Inch) | 0.1520 |
