Titan USA - Spiral Point Taps; Thread Size (Inch): #10-32 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H3 ; Finish/Coating: Nitride/Steam Oxide
Item #: 07973662
Brand: Titan USA
Model #: TT91040NS
Product Specifications
Spiral Point Taps; Thread Size (Inch): #10-32 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H3 ; Finish/Coating: Nitride/Steam Oxide
Thread Size (Inch) | #10-32 |
Number of Flutes | 2 |
Chamfer | Plug |
Class of Fit | 2B/3B |
Thread Limit | H3 |
Finish/Coating | Nitride/Steam Oxide |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 2.3750 |
Overall Length (Inch) | 2-3/8 |
Thread Standard | UNF |
Thread Length (Decimal Inch) | 0.8750 |
Thread Length (Inch) | 7/8 |
Series/List | 752 |
Shank Diameter (Decimal Inch) | 0.1940 |
Square Length (Inch) | 1/4 |
Square Size (Decimal Inch) | 0.1520 |
