Titan USA - Spiral Point Taps; Thread Size (Inch): #12-24 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H3 ; Finish/Coating: Nitride/Steam Oxide
Item #: 07973605
Brand: Titan USA
Model #: TT91043NS
Product Specifications
Spiral Point Taps; Thread Size (Inch): #12-24 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H3 ; Finish/Coating: Nitride/Steam Oxide
Thread Size (Inch) | #12-24 |
Number of Flutes | 2 |
Chamfer | Plug |
Class of Fit | 2B/3B |
Thread Limit | H3 |
Finish/Coating | Nitride/Steam Oxide |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 2.3750 |
Overall Length (Inch) | 2-3/8 |
Thread Standard | UNC |
Thread Length (Decimal Inch) | 0.9375 |
Thread Length (Inch) | 15/16 |
Series/List | 752 |
Shank Diameter (Decimal Inch) | 0.2200 |
Square Length (Inch) | 0.2813 |
Square Size (Decimal Inch) | 0.1650 |
