![Titan USA - Spiral Point Taps; Thread Size (Inch): #12-28 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H3 ; Finish/Coating: Uncoated - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0795379-21_4185b03c-45e6-4896-80ef-5c34410cc670_1024x1024.jpg?v=1638996687)
Titan USA - Spiral Point Taps; Thread Size (Inch): #12-28 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H3 ; Finish/Coating: Uncoated
Item #: 07973589
Brand: Titan USA
Model #: TT91044
Product Specifications
Spiral Point Taps; Thread Size (Inch): #12-28 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 2B/3B ; Thread Limit: H3 ; Finish/Coating: Uncoated
Thread Size (Inch) | #12-28 |
Number of Flutes | 2 |
Chamfer | Plug |
Class of Fit | 2B/3B |
Thread Limit | H3 |
Finish/Coating | Uncoated |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 2.3750 |
Overall Length (Inch) | 2-3/8 |
Thread Standard | UNF |
Thread Length (Decimal Inch) | 0.9375 |
Thread Length (Inch) | 15/16 |
Series/List | 750 |
Shank Diameter (Decimal Inch) | 0.2200 |
Square Length (Inch) | 0.2813 |
Square Size (Decimal Inch) | 0.1650 |
