Titan USA - Spiral Point Taps; Thread Size (Inch): #6-32 ; Number of Flutes: 2 ; Chamfer: Plug ; Thread Limit: H7 ; Finish/Coating: Uncoated ; Material: High Speed Steel
Item #: 07973324
Brand: Titan USA
Model #: TT91025
Product Specifications
Spiral Point Taps; Thread Size (Inch): #6-32 ; Number of Flutes: 2 ; Chamfer: Plug ; Thread Limit: H7 ; Finish/Coating: Uncoated ; Material: High Speed Steel
Thread Size (Inch) | #6-32 |
Number of Flutes | 2 |
Chamfer | Plug |
Thread Limit | H7 |
Finish/Coating | Uncoated |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 2.0000 |
Overall Length (Inch) | 2 |
Thread Standard | UNC |
Thread Length (Decimal Inch) | 0.6875 |
Thread Length (Inch) | 11/16 |
Series/List | 750 |
Shank Diameter (Decimal Inch) | 0.1410 |
Square Length (Inch) | 3/16 |
Square Size (Decimal Inch) | 0.1100 |
Square Size (mm) | 2.80 |
