![Titan USA - 5/16-24 Bottoming RH 2B/3B H3 Uncoated High Speed Steel 4-Flute Straight Flute Hand Tap - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0795183-21_9f4ea5b7-b6a1-452a-bcb7-d6cd2a8df740_1024x1024.jpg?v=1638997051)
Titan USA - 5/16-24 Bottoming RH 2B/3B H3 Uncoated High Speed Steel 4-Flute Straight Flute Hand Tap
Item #: 07969488
Brand: Titan USA
Model #: TT90401
Product Specifications
Tap Type | Standard Hand Tap |
Thread Size (Inch) | 5/16-24 |
Class of Fit | 2B/3B |
Thread Limit | H3 |
Number of Flutes | 4 |
Chamfer | Bottoming |
Material | High Speed Steel |
Finish/Coating | Uncoated |
Thread Direction | Right Hand |
Through Coolant | NonThrough Coolant |
Thread Standard | UNF |
Overall Length (Decimal Inch) | 2.7188 |
Series/List | 725 |
Thread Length (Decimal Inch) | 1.1250 |
Thread Length (Inch) | 1-1/8 |
Square Length (Inch) | 3/8 |
Square Size (Decimal Inch) | 0.2380 |
