Titan USA - #5-40 Taper RH 2B/3B H2 Uncoated High Speed Steel 3-Flute Straight Flute Hand Tap
Item #: 07964984
Brand: Titan USA
Model #: TT90100
Product Specifications
| Tap Type | Standard Hand Tap |
| Thread Size (Inch) | #5-40 |
| Class of Fit | 2B/3B |
| Thread Limit | H2 |
| Number of Flutes | 3 |
| Chamfer | Taper |
| Material | High Speed Steel |
| Finish/Coating | Uncoated |
| Thread Direction | Right Hand |
| Through Coolant | NonThrough Coolant |
| Thread Standard | UNC |
| Overall Length (Decimal Inch) | 1.9375 |
| Overall Length (Inch) | 1-15/16 |
| Series/List | 725 |
| Thread Length (Decimal Inch) | 0.6250 |
| Thread Length (Inch) | 5/8 |
| Square Length (Inch) | 3/16 |
| Square Size (Decimal Inch) | 0.1100 |
| Square Size (mm) | 2.80 |
