![Titan USA - #4-48 Bottoming RH 2B/3B H2 Uncoated High Speed Steel 3-Flute Straight Flute Hand Tap - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0795183-21_51a50b37-2663-4dfd-8d26-55c1cd4200aa_1024x1024.jpg?v=1638997028)
Titan USA - #4-48 Bottoming RH 2B/3B H2 Uncoated High Speed Steel 3-Flute Straight Flute Hand Tap
Item #: 07964794
Brand: Titan USA
Model #: TT90086
Product Specifications
Tap Type | Standard Hand Tap |
Thread Size (Inch) | #4-48 |
Class of Fit | 2B/3B |
Thread Limit | H2 |
Number of Flutes | 3 |
Chamfer | Bottoming |
Material | High Speed Steel |
Finish/Coating | Uncoated |
Thread Direction | Right Hand |
Through Coolant | NonThrough Coolant |
Thread Standard | UNF |
Overall Length (Decimal Inch) | 1.8750 |
Overall Length (Inch) | 1-7/8 |
Series/List | 725 |
Thread Length (Decimal Inch) | 0.5625 |
Thread Length (Inch) | 9/16 |
Square Length (Inch) | 3/16 |
Square Size (Decimal Inch) | 0.1100 |
Square Size (mm) | 2.80 |
