Titan USA - #5-44 Bottoming RH 2B/3B H2 Uncoated High Speed Steel 3-Flute Straight Flute Hand Tap
Item #: 07957905
Brand: Titan USA
Model #: TT90110
Product Specifications
Tap Type | Standard Hand Tap |
Thread Size (Inch) | #5-44 |
Class of Fit | 2B/3B |
Thread Limit | H2 |
Number of Flutes | 3 |
Chamfer | Bottoming |
Material | High Speed Steel |
Finish/Coating | Uncoated |
Thread Direction | Right Hand |
Through Coolant | NonThrough Coolant |
Thread Standard | UNF |
Overall Length (Decimal Inch) | 1.9375 |
Overall Length (Inch) | 1-15/16 |
Series/List | 725 |
Thread Length (Decimal Inch) | 0.6250 |
Thread Length (Inch) | 5/8 |
Square Length (Inch) | 3/16 |
Square Size (Decimal Inch) | 0.1100 |
Square Size (mm) | 2.80 |
