Titan USA - #6-32 Bottoming RH 3B H1 Uncoated High Speed Steel 3-Flute Straight Flute Hand Tap
Item #: 07957863
Brand: Titan USA
Model #: TT90118
Product Specifications
Tap Type | Standard Hand Tap |
Thread Size (Inch) | #6-32 |
Class of Fit | 3B |
Thread Limit | H1 |
Number of Flutes | 3 |
Chamfer | Bottoming |
Material | High Speed Steel |
Finish/Coating | Uncoated |
Thread Direction | Right Hand |
Through Coolant | NonThrough Coolant |
Thread Standard | UNC |
Overall Length (Decimal Inch) | 2.0000 |
Overall Length (Inch) | 2 |
Series/List | 725 |
Thread Length (Decimal Inch) | 0.6875 |
Thread Length (Inch) | 11/16 |
Square Length (Inch) | 3/16 |
Square Size (Decimal Inch) | 0.1100 |
Square Size (mm) | 2.80 |
