Titan USA - Spiral Point Taps; Thread Size (Inch): #5-40 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 3B ; Thread Limit: H1 ; Finish/Coating: Uncoated
Item #: 07953813
Brand: Titan USA
Model #: TT91019
Product Specifications
Spiral Point Taps; Thread Size (Inch): #5-40 ; Number of Flutes: 2 ; Chamfer: Plug ; Class of Fit: 3B ; Thread Limit: H1 ; Finish/Coating: Uncoated
Thread Size (Inch) | #5-40 |
Number of Flutes | 2 |
Chamfer | Plug |
Class of Fit | 3B |
Thread Limit | H1 |
Finish/Coating | Uncoated |
Material | High Speed Steel |
Through Coolant | NonThrough Coolant |
Thread Direction | Right Hand |
Overall Length (Decimal Inch) | 1.9375 |
Overall Length (Inch) | 1-15/16 |
Thread Standard | UNC |
Thread Length (Decimal Inch) | 0.6250 |
Thread Length (Inch) | 5/8 |
Series/List | 750 |
Shank Diameter (Decimal Inch) | 0.1410 |
Square Length (Inch) | 3/16 |
Square Size (Decimal Inch) | 0.1100 |
Square Size (mm) | 2.80 |
