Titan USA - #12-24 Bottoming RH 2B/3B H3 Uncoated High Speed Steel 4-Flute Straight Flute Hand Tap
Item #: 07953045
Brand: Titan USA
Model #: TT90290S
Product Specifications
Tap Type | Standard Hand Tap |
Thread Size (Inch) | #12-24 |
Class of Fit | 2B/3B |
Thread Limit | H3 |
Number of Flutes | 4 |
Chamfer | Bottoming |
Material | High Speed Steel |
Finish/Coating | Uncoated |
Thread Direction | Right Hand |
Through Coolant | NonThrough Coolant |
Thread Standard | UNC |
Overall Length (Decimal Inch) | 2.3750 |
Overall Length (Inch) | 2-3/8 |
Series/List | 726 |
Thread Length (Decimal Inch) | 0.9375 |
Thread Length (Inch) | 15/16 |
Square Length (Inch) | 0.2813 |
Square Size (Decimal Inch) | 0.1650 |
