Titan USA - 1/4-28 Bottoming RH 2B/3B H3 Uncoated High Speed Steel 2-Flute Straight Flute Hand Tap
Item #: 07952757
Brand: Titan USA
Model #: TT90345
Product Specifications
Tap Type | Standard Hand Tap |
Thread Size (Inch) | 1/4-28 |
Class of Fit | 2B/3B |
Thread Limit | H3 |
Number of Flutes | 2 |
Chamfer | Bottoming |
Material | High Speed Steel |
Finish/Coating | Uncoated |
Thread Direction | Right Hand |
Through Coolant | NonThrough Coolant |
Thread Standard | UNF |
Overall Length (Decimal Inch) | 2.5000 |
Overall Length (Inch) | 2-1/2 |
Series/List | 725 |
Thread Length (Decimal Inch) | 1.0000 |
Thread Length (Inch) | 1 |
Square Length (Inch) | 5/16 |
Square Size (Decimal Inch) | 0.1910 |
