GC/Waldom - SPST, Maintained (MA), On-None-Off Sequence, Appliance Rocket Switch - 15 Amps at 125 Volts, 10 Amps at 250 Volts, 3/4 hp at 125/250 VAC, Quick Connect, Panel Mount
Item #: 07511264
Brand: GC/Waldom
Model #: 35-3600
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Switch Type | Appliance |
| Switch Sequence | On-None-Off |
| Contact Form | SPST |
| Operation Type | Maintained (MA) |
| Terminal Type | Quick Connect |
| Maximum Amperage at 125 Volts | 15 |
| Maximum Amperage at 250 Volts | 10 |
| Voltage | 250 VAC |
| Horsepower (HP) | 3/4 @ 125/250 VAC |
| Mounting Type | Panel Mount |
| Switch Shape | Rectangle |
| Color | Black |
| Mounting Hole Length (Decimal Inch) | 1.4500 |
| Mounting Hole Width (Decimal Inch) | 0.8300 |
| Standards Met | CSA; UL Recognized |
