Heli-Coil - Single Insert, M6x1 Metric Coarse, 2D, Stainless Steel Screw Locking Insert - 9-1/2 Free Coils, 12mm Overall Length, 7.4 to 7.95mm Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 07208473
Brand: Heli-Coil
Model #: A4184-6CNW120
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M6x1.00 |
Overall Insert Length (mm) | 12.00 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 7.40 |
Maximum Outside Diameter (mm) | 7.95 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 9-1/2 |
Maximum Locking Torque (N/m) | 3.00 |
Minimum Break Away Torque (N/m) | 0.4000 |
Thread Standard | Metric Coarse |
Material Grade | 304 |
