![Heli-Coil - Single Insert, 7/16-14 UNC, 2D, Stainless Steel Screw Locking Insert - 10-1/4 Free Coils, 7/8 Inch Overall Length, 0.526 to 0.551 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3288565-11_f611daf2-0493-4c89-ba49-81771a46c899_1024x1024.jpg?v=1586462885)
Heli-Coil - Single Insert, 7/16-14 UNC, 2D, Stainless Steel Screw Locking Insert - 10-1/4 Free Coils, 7/8 Inch Overall Length, 0.526 to 0.551 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 07146111
Brand: Heli-Coil
Model #: A3585-7CNW875
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 7/16-14 |
Overall Insert Length (Decimal Inch) | 0.8750 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.5260 |
Maximum Outside Diameter (Decimal Inch) | 0.5510 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 10-1/4 |
Maximum Locking Torque (In/Lb) | 100 |
Minimum Break Away Torque (In/Lb) | 16.50 |
Thread Standard | UNC |
Material Grade | 304 |
