![Mitutoyo - 120" Max Measuring Range, 1 µm Resolution, 127" Scale Length, Electromagnetic DRO Linear Scale - 10 µm Accuracy, IP67, 7,000' Cable Length, 0 to 45°C, Series AT715 - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0704098-11_80f4e503-3127-454e-8183-47663282dc21_1024x1024.jpg?v=1585919674)
Mitutoyo - 120" Max Measuring Range, 1 µm Resolution, 127" Scale Length, Electromagnetic DRO Linear Scale - 10 µm Accuracy, IP67, 7,000' Cable Length, 0 to 45°C, Series AT715
Item #: 07041049
Brand: Mitutoyo
Model #: 539-866
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Scale Type | Electromagnetic |
Maximum Measuring Range (mm) | 3040.00 |
Maximum Measuring Range (Inch) | 120 |
Maximum Measuring Range (Decimal Inch) | 119.6800 |
Resolution (Micron) | 1.00 |
Scale Length (mm) | 3198.00 |
Scale Length (Inch) | 127 |
Scale Length (Decimal Inch) | 125.9100 |
Accuracy (micrometer) | 10.00 |
Series | AT715 |
IP Rating | IP67 |
Cable Length (mm) | 7000.00 |
Cable Length (Decimal Inch) | 275.5910 |
Operating Temperature Range (C) | 0 to 45 |
Storage Temperature Range (C) | -20 to 70 |
