![Collis Tool - 5/8" ID, 1-1/4" OD, 2-1/8" Length Under Head, Type J Lathe Tool Holder Bushing - 5/8" Hole Diam, 3/16" Head Thickness - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0587900-11_852b3439-357c-45b6-88ed-f0294acf6ad8_1024x1024.jpg?v=1586513941)
Collis Tool - 5/8" ID, 1-1/4" OD, 2-1/8" Length Under Head, Type J Lathe Tool Holder Bushing - 5/8" Hole Diam, 3/16" Head Thickness
Item #: 05879036
Brand: Collis Tool
Model #: 85422
Exact Tooling IR#: 04
Features and Benefits
J toolholder bushings are designed with a long solid body and two cearance holes for set screw clamping directly onto the tool.
Product Specifications | |
---|---|
Type | J |
Outside Diameter (Decimal Inch) | 1.2500 |
Outside Diameter (Inch) | 1-1/4 |
Inside Diameter (Inch) | 5/8 |
Inside Diameter (Decimal Inch) | 0.6250 |
Head Thickness (Inch) | 3/16 |
Head Thickness (Decimal Inch) | 0.1875 |
Length Under Head (Inch) | 2-1/8 |
Length Under Head (Decimal Inch) | 2.1250 |
Distance Between Hole Centers (Inch) | 1 |
Hole Diameter (Decimal Inch) | 0.6250 |
