![Collis Tool - 1/2" ID, 3/4" OD, 1-1/2" Length Under Head, Type J Lathe Tool Holder Bushing - 3/8" Hole Diam, 3/16" Head Thickness - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0587900-11_70597c52-9419-4182-bc18-e0a8c6ccae43_1024x1024.jpg?v=1586716224)
Collis Tool - 1/2" ID, 3/4" OD, 1-1/2" Length Under Head, Type J Lathe Tool Holder Bushing - 3/8" Hole Diam, 3/16" Head Thickness
Item #: 05878962
Brand: Collis Tool
Model #: 85403
Exact Tooling IR#: 04
Features and Benefits
J toolholder bushings are designed with a long solid body and two cearance holes for set screw clamping directly onto the tool.
Product Specifications | |
---|---|
Type | J |
Outside Diameter (Decimal Inch) | 0.7500 |
Outside Diameter (Inch) | 3/4 |
Inside Diameter (Inch) | 1/2 |
Inside Diameter (Decimal Inch) | 0.5000 |
Head Thickness (Inch) | 3/16 |
Head Thickness (Decimal Inch) | 0.1875 |
Length Under Head (Inch) | 1-1/2 |
Length Under Head (Decimal Inch) | 1.5000 |
Distance Between Hole Centers (Decimal Inch) | 0.8120 |
Hole Diameter (Decimal Inch) | 0.3750 |
