Vermont Tap & Die - 1/4-20 UNC, 2 Flute, TiN Finish, High Speed Steel Spiral Point Tap - Bottoming Chamfer, Right Hand Thread, 2-1/2" OAL, 1" Thread Length, 6.48mm Shank Diam, 2/3B Class of Fit, Series TN3112
Item #: 05003561
Brand: Vermont Tap & Die
Model #: 357054
Exact Tooling IR#: 04
Features and Benefits
Bottoming chamfers are used for threading blind holes. They have 1 to 2 threads.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
High Speed Steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
| Product Specifications | |
|---|---|
| Thread Size (Inch) | 1/4-20 |
| Number of Flutes | 2 |
| Chamfer | Bottoming |
| Class of Fit | 2/3B |
| Thread Limit | H3 |
| Finish/Coating | TiN |
| Material | High Speed Steel |
| Through Coolant | NonThrough Coolant |
| Thread Direction | Right Hand |
| Overall Length (Decimal Inch) | 2.5000 |
| Overall Length (Inch) | 2-1/2 |
| Overall Length (mm) | 63.50 |
| Oversize | No |
| Thread Standard | UNC |
| Thread Length (Decimal Inch) | 1.0000 |
| Thread Length (Inch) | 1 |
| Thread Length (mm) | 25.40 |
| Series/List | TN3112 |
| Style | Spiral Point |
| Shank Diameter (Decimal Inch) | 0.2550 |
| Shank Diameter (mm) | 6.48 |
| Square Length (Inch) | 5/16 |
| Square Size (Decimal Inch) | 0.1910 |
| Square Size (mm) | 4.85 |
| Material Application | Alloy Steel; Aluminum Alloys; Carbon Steel; Cast Iron; Copper Alloys; Graphites & Carbons; High Temperature Alloys; Magnesium; Plastics; Stainless Steel; Titanium; Tool Steel; Zinc Alloys |
