Interstate - 1 - 11-1/2 NPT, 5 Flute, Plug Chamfer, Bright Finish, High Speed Steel, Extension Pipe Tap - 12" OAL, 1-1/8" Shank Diam, 1-3/4" Thread Length, 0.843" Square Size - Exact Industrial Supply

Interstate - 1 - 11-1/2 NPT, 5 Flute, Plug Chamfer, Bright Finish, High Speed Steel, Extension Pipe Tap - 12" OAL, 1-1/8" Shank Diam, 1-3/4" Thread Length, 0.843" Square Size


Item #: 04679098
Brand: Interstate
Exact Tooling IR#: 04

Features and Benefits

NPT (National Pipe Taper) refers to American National Standard Taper Pipe Threads. They are commonly used for general purpose applications and require a sealant.
High Speed Steel (HSS) provides good wear-resistance and can be used in general purpose applications for both ferrous and non-ferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Standard extension pipe taps are used for internal deep-hole drilling of pipes and pipe fittings. ideal for hard-to-reach-areas in general purpose applications..
Plug chamfers are the most commonly used chamfer and are designed for efficiently threading through and blind holes. They have 3 to 5 threads.
Product Specifications
Thread Size (Inch) 1 - 11-1/2
Thread Standard NPT
Material High Speed Steel
Finish/Coating Bright
Number of Flutes 5
Thread Profile Standard
Chamfer Plug
Overall Length (Inch) 12
Thread Length (Inch) 1-3/4
Shank Diameter (Decimal Inch) 1.1250
Square Size (Decimal Inch) 0.8430
Projection (Decimal Inch) 0.6780
$421.10
