Heli-Coil - Single Insert, 1/4-20 UNC, 2D, Nitronic 60 Stainless Steel Screw Locking Insert - 8 Free Coils, 1/2 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, 18-8 Material Grade
Item #: 03585437
Brand: Heli-Coil
Model #: A3585-4EN500
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 1/4-20 |
| Overall Insert Length (Decimal Inch) | 0.5000 |
| Tang | Tangless |
| Length to Diameter Ratio | 2D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.3100 |
| Maximum Outside Diameter (Decimal Inch) | 0.3300 |
| Number of Free Coils | 8 |
| Maximum Locking Torque (In/Lb) | 30 |
| Minimum Break Away Torque (In/Lb) | 4.50 |
| Thread Standard | UNC |
| Material Grade | 18-8 |
