![Heli-Coil - Single Insert, #10-32 UNF, 1-1/2D, Nitronic 60 Stainless Steel Screw Locking Insert - 6-7/8 Free Coils, 0.285 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, with Tang, 18-8 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0358539-23_1024x1024.jpg?v=1586838233)
Heli-Coil - Single Insert, #10-32 UNF, 1-1/2D, Nitronic 60 Stainless Steel Screw Locking Insert - 6-7/8 Free Coils, 0.285 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, with Tang, 18-8 Material Grade
Item #: 03585395
Brand: Heli-Coil
Model #: A3591-3EN285
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #10-32 |
Overall Insert Length (Decimal Inch) | 0.2850 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2360 |
Maximum Outside Diameter (Decimal Inch) | 0.2560 |
Number of Free Coils | 6-7/8 |
Maximum Locking Torque (In/Lb) | 13 |
Mininum Break Away Torque (oz-in) | 2.00 |
Thread Standard | UNF |
Material Grade | 18-8 |
