Corner Chamfer End Mill: 0.5″ Dia, 0.625″ LOC, 3 Flute, 0.006 to 0.009″ Chamfer Width, Solid Carbide 3″ OAL, 1/2″ Shank Dia, 40 ° Helix, AlTiN Coated, Centercutting

Corner Chamfer End Mill: 0.5″ Dia, 0.625″ LOC, 3 Flute, 0.006 to 0.009″ Chamfer Width, Solid Carbide 3″ OAL, 1/2″ Shank Dia, 40 ° Helix, AlTiN Coated, Centercutting


Item #: 03516218
Brand: RobbJack
Model #: ST-341-16-A

Product Specifications

Mill Diameter (Decimal Inch) 0.5000
Chamfer Width (Decimal Inch) 0.0060 to 0.0090
Mill Diameter (Inch) 1/2
Chamfer Angle 45
Length of Cut (Inch) 5/8
Number Of Flutes 3
End Mill Material Solid Carbide
Extended Reach No
End Type Corner Chamfer
Length Type Stub
Flute Type Spiral
Helix Angle 40
Centercutting Yes
Variable Index No
Variable Helix No
Shank Diameter (Inch) 1/2
Overall Length (Inch) 3
Overall Length (Decimal Inch) 3.0000
Maximum Helix Angle 40.00
Mill Diameter Tolerance +0.000 to -0.003 in
Shank Diameter Tolerance -0.0001 to -0.0002 in
Overall Length Tolerance +0.060 to -0.060 in
Primary Workpiece Material Code P; S; K; M
Cutting Direction Right Hand
Flute Direction Right Hand
Series ST-341
Single Or Double End Single
Coating/Finish AlTiN
Length Of Cut (Decimal Inch - 4 Decimals) 0.6250
$86.72
