Heli-Coil - Single Insert, #2-56 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5-1/4 Free Coils, 0.129 Inch Overall Length, 0.11 to 0.119 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 03112836
Brand: Heli-Coil
Model #: A3585-02CNW129
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #2-56 |
Overall Insert Length (Decimal Inch) | 0.1290 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1100 |
Maximum Outside Diameter (Decimal Inch) | 0.1190 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 5-1/4 |
Maximum Locking Torque (oz-in) | 20 |
Mininum Break Away Torque (oz-in) | 3.00 |
Thread Standard | UNC |
Material Grade | 304 |
