![Heli-Coil - Single Insert, 7/16-20 UNF, 1D, Stainless Steel Screw Locking Insert - 6-5/8 Free Coils, 7/16 Inch Overall Length, 0.524 to 0.549 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/3288565-11_a6f85389-9abc-452d-861c-78cbddebcae5_1024x1024.jpg?v=1586461535)
Heli-Coil - Single Insert, 7/16-20 UNF, 1D, Stainless Steel Screw Locking Insert - 6-5/8 Free Coils, 7/16 Inch Overall Length, 0.524 to 0.549 Inch Outside Diameter, with Tang, Dry Film Lubricant, 304 Material Grade
Item #: 03101797
Brand: Heli-Coil
Model #: A3591-7CNW438
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 7/16-20 |
Overall Insert Length (Decimal Inch) | 0.4380 |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.5240 |
Maximum Outside Diameter (Decimal Inch) | 0.5490 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 6-5/8 |
Maximum Locking Torque (In/Lb) | 100 |
Mininum Break Away Torque (oz-in) | 14.00 |
Minimum Break Away Torque (In/Lb) | 14.00 |
Thread Standard | UNF |
Material Grade | 304 |
