Made in USA - 21.5mm Diam, 90° Tooth Angle, 25 TPI, Standard (Shape), Cut Type Cobalt Left-Hand Diagonal Knurl Wheel - 5mm Face Width, 8mm Hole, Circular Pitch, 30° Helix, Bright Finish, Series CC - Exact Industrial Supply

Made in USA - 21.5mm Diam, 90° Tooth Angle, 25 TPI, Standard (Shape), Cut Type Cobalt Left-Hand Diagonal Knurl Wheel - 5mm Face Width, 8mm Hole, Circular Pitch, 30° Helix, Bright Finish, Series CC


Item #: 02382364
Brand: Made in USA
Exact Tooling IR#: 04

Features and Benefits

Left-hand diagonal wheels are designed to produce right-hand diagonal patterns. On a two-wheel knurling tool, left and right diagonal wheels are used together to create a diamond design.
Cut type wheels produce textured patterns by cutting into and removing material from the workpiece. They reduce the diameter of the workpiece as the pattern is applied.
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
Product Specifications
Knurl Shape Standard
Pattern Left-Hand Diagonal
Form or Cut Type Cut
Material Cobalt
Knurl Diameter (mm) 21.50
Face Width (mm) 5.00
Hole Diameter (mm) 8.00
Pitch System Circular
Pitch (mm) 1.00
Pitch (TPI) 25
Knurl Series CC
Included Tooth Angle 90
Finish/Coating Bright
Helix Angle 30
$48.28
