Sumitomo - VPMA443 Grade DA2200 Polycrystalline Diamond (PCD) Turning Insert - Uncoated, 35° Diamond, 1/2" Inscr Circle, 1/4" Thick, 3/64" Corner Radius
Item #: 02254027
Brand: Sumitomo
Model #: 16CDWBS
Exact Tooling IR#: 04
Features and Benefits
Polycrystalline Diamond (PCD) is a synthetic diamond. It is shock resistant, wear resistant and allows for cutting at high speeds on nonferrous material.
Product Specifications | |
---|---|
Insert Style | VPMA |
Insert Size | 443 |
Material | Polycrystalline Diamond (PCD) |
Inscribed Circle (mm) | 12.70 |
Inscribed Circle (Decimal Inch) | 0.5000 |
Inscribed Circle (Inch) | 1/2 |
Thickness (Inch) | 1/4 |
Thickness (Decimal Inch) | 0.2500 |
Corner Radius (Inch) | 3/64 |
Corner Radius (Decimal Inch) | 0.0469 |
Manufacturer's Grade | DA2200 |
Coating | Uncoated |
Rake | Neutral |
Rake Angle | 0 |
Relief Angle | 11 |
Included Angle | 35 |
Insert Holding Method | Screw |
Shape | Diamond |
