Recoil - 7/16-14 UNC, 2D, Stainless Steel Screw Locking Insert - 10-1/4 Free Coils, 7/8 Inch Overall Length, 0.526 to 0.551 Inch Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply

Recoil - 7/16-14 UNC, 2D, Stainless Steel Screw Locking Insert - 10-1/4 Free Coils, 7/8 Inch Overall Length, 0.526 to 0.551 Inch Outside Diameter, with Tang, Bright Finish


Item #: 01662097
Brand: Recoil
Model #: 13074
Exact Tooling IR#: 04

Product Specifications
Thread Size 7/16-14
Overall Insert Length (Decimal Inch) 0.8750
Tang Tangless
Length to Diameter Ratio 2D
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.5260
Maximum Outside Diameter (Decimal Inch) 0.5510
Finish/Coating Bright
Number of Free Coils 10-1/4
Maximum Locking Torque (In/Lb) 100
Minimum Break Away Torque (In/Lb) 16.50
Thread Standard UNC
$2.73

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
