Kennametal - 1" Cut Diam, 14mm Max Depth of Cut, 1" Shank Diam, 146.81mm OAL, Indexable Square Shoulder End Mill - EC14.., EP14.. Inserts, Weldon Shank, 0° Lead Angle
Item #: 01032218
Brand: Kennametal
Model #: 2624191
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 1.0000 |
| Cutting Diameter (Inch) | 1 |
| Shank Type | Weldon |
| Shank Diameter (mm) | 25.40 |
| Shank Diameter (Inch) | 1 |
| Shank Diameter (Decimal Inch) | 1.0000 |
| Overall Length/Projection (mm) | 146.81 |
| Overall Length/Projection (Decimal Inch) | 5.7800 |
| Lead Angle | 0 |
| Through Coolant | Noncoolant Through |
| Maximum Depth of Cut (mm) | 14.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.5510 |
| Number of Cutter Inserts | 3 |
| Insert Holding Method | Screw |
| End Mill Type | End Mill |
| Cutter Style | Mill 1 |
| Number of Flutes | 3 |
| Head Length (mm) | 44.45 |
| Head Length (Decimal Inch) | 1.7500 |
| Weldon Flat | Yes |
| Insert Compatibility | EC14.., EP14.. |
| Shank Length (Decimal Inch) | 2.2799 |
| Shank Length (mm) | 57.91 |
| Maximum RPM | 39200 |
