![Heli-Coil - Single Insert, #10-32 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 6-7/8 Free Coils, 0.285 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, Tangless, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0066455-21_1024x1024.jpg?v=1586838239)
Heli-Coil - Single Insert, #10-32 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 6-7/8 Free Coils, 0.285 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, Tangless, Bright Finish, 304 Material Grade
Item #: 00664557
Brand: Heli-Coil
Model #: AT3591-3C285
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #10-32 |
Overall Insert Length (Decimal Inch) | 0.2850 |
Tang | Tanged |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2360 |
Maximum Outside Diameter (Decimal Inch) | 0.2560 |
Finish/Coating | Bright |
Number of Free Coils | 6-7/8 |
Maximum Locking Torque (In/Lb) | 13 |
Minimum Break Away Torque (In/Lb) | 2.00 |
Thread Standard | UNF |
Material Grade | 304 |
