Heli-Coil - Single Insert, #10-32 UNF, 1D, Stainless Steel Screw Locking Insert - 4-1/8 Free Coils, 0.19 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, Tangless, Bright Finish, 304 Material Grade
Item #: 00664540
Brand: Heli-Coil
Model #: AT3591-3C190
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #10-32 |
| Overall Insert Length (Decimal Inch) | 0.1900 |
| Tang | Tanged |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.2360 |
| Maximum Outside Diameter (Decimal Inch) | 0.2560 |
| Finish/Coating | Bright |
| Number of Free Coils | 4-1/8 |
| Maximum Locking Torque (In/Lb) | 13 |
| Minimum Break Away Torque (In/Lb) | 2.00 |
| Thread Standard | UNF |
| Material Grade | 304 |
