Heli-Coil - Single Insert, #6-32 UNC, 1D, Stainless Steel Screw Locking Insert - 2-3/4 Free Coils, 0.138 Inch Overall Length, 0.178 to 0.193 Inch Outside Diameter, Tangless, Bright Finish, 304 Material Grade - Exact Industrial Supply

Heli-Coil - Single Insert, #6-32 UNC, 1D, Stainless Steel Screw Locking Insert - 2-3/4 Free Coils, 0.138 Inch Overall Length, 0.178 to 0.193 Inch Outside Diameter, Tangless, Bright Finish, 304 Material Grade


Item #: 00664482
Brand: Heli-Coil
Model #: AT3585-06C138
Exact Tooling IR#: 04

Product Specifications
Thread Size #6-32
Overall Insert Length (Decimal Inch) 0.1380
Tang Tanged
Length to Diameter Ratio 1D
Number of Inserts 1
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.1780
Maximum Outside Diameter (Decimal Inch) 0.1930
Finish/Coating Bright
Number of Free Coils 2-3/4
Maximum Locking Torque (In/Lb) 6
Minimum Break Away Torque (In/Lb) 1.00
Thread Standard UNC
Material Grade 304
$0.94
