![Heli-Coil - Single Insert, #4-40 UNC, 1D, Stainless Steel Screw Locking Insert - 2-3/4 Free Coils, 0.112 Inch Overall Length, 0.144 to 0.159 Inch Outside Diameter, Tangless, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0066445-21_1024x1024.jpg?v=1586838318)
Heli-Coil - Single Insert, #4-40 UNC, 1D, Stainless Steel Screw Locking Insert - 2-3/4 Free Coils, 0.112 Inch Overall Length, 0.144 to 0.159 Inch Outside Diameter, Tangless, Bright Finish, 304 Material Grade
Item #: 00664458
Brand: Heli-Coil
Model #: AT3585-04C112
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #4-40 |
Overall Insert Length (Decimal Inch) | 0.1120 |
Tang | Tanged |
Length to Diameter Ratio | 1D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1440 |
Maximum Outside Diameter (Decimal Inch) | 0.1590 |
Finish/Coating | Bright |
Number of Free Coils | 2-3/4 |
Maximum Locking Torque (oz-in) | 48 |
Mininum Break Away Torque (oz-in) | 10.00 |
Thread Standard | UNC |
Material Grade | 304 |
