Heli-Coil - Single Insert, 5/8-11 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 8-1/2 Free Coils, 15/16 Inch Overall Length, 0.742 to 0.767 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00063669
Brand: Heli-Coil
Model #: A3585-10CN938
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 5/8-11 |
Overall Insert Length (Decimal Inch) | 0.9380 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.7420 |
Maximum Outside Diameter (Decimal Inch) | 0.7670 |
Finish/Coating | Bright |
Number of Free Coils | 8-1/2 |
Maximum Locking Torque (In/Lb) | 300 |
Minimum Break Away Torque (In/Lb) | 40.00 |
Thread Standard | UNC |
Material Grade | 304 |
