Heli-Coil - Single Insert, 1/2-13 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 7-7/8 Free Coils, 3/4 Inch Overall Length, 0.597 to 0.622 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00063461
Brand: Heli-Coil
Model #: A3585-8CN750
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 1/2-13 |
| Overall Insert Length (Decimal Inch) | 0.7500 |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.5970 |
| Maximum Outside Diameter (Decimal Inch) | 0.6220 |
| Finish/Coating | Bright |
| Number of Free Coils | 7-7/8 |
| Maximum Locking Torque (In/Lb) | 150 |
| Minimum Break Away Torque (In/Lb) | 24.00 |
| Thread Standard | UNC |
| Material Grade | 304 |
