![Heli-Coil - Single Insert, 7/16-20 UNF, 2D, Stainless Steel Screw Locking Insert - 14-5/8 Free Coils, 7/8 Inch Overall Length, 0.524 to 0.549 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/5693743-11_d6dceb07-7cb7-4fef-a122-41ec2600564f_1024x1024.jpg?v=1586460455)
Heli-Coil - Single Insert, 7/16-20 UNF, 2D, Stainless Steel Screw Locking Insert - 14-5/8 Free Coils, 7/8 Inch Overall Length, 0.524 to 0.549 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00063420
Brand: Heli-Coil
Model #: A3591-7CN875
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 7/16-20 |
Overall Insert Length (Decimal Inch) | 0.8750 |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.5240 |
Maximum Outside Diameter (Decimal Inch) | 0.5490 |
Finish/Coating | Bright |
Number of Free Coils | 14-5/8 |
Maximum Locking Torque (In/Lb) | 100 |
Mininum Break Away Torque (oz-in) | 14.00 |
Thread Standard | UNF |
Material Grade | 304 |
