Heli-Coil - Single Insert, 5/16-24 UNF, 1D, Stainless Steel Screw Locking Insert - 5-1/2 Free Coils, 5/16 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply

Heli-Coil - Single Insert, 5/16-24 UNF, 1D, Stainless Steel Screw Locking Insert - 5-1/2 Free Coils, 5/16 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade


Item #: 00063206
Brand: Heli-Coil
Model #: A3591-5CN312
Exact Tooling IR#: 04

Product Specifications
Thread Size 5/16-24
Overall Insert Length (Decimal Inch) 0.3120
Tang Tangless
Length to Diameter Ratio 1D
Number of Inserts 1
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.3800
Maximum Outside Diameter (Decimal Inch) 0.4000
Finish/Coating Bright
Number of Free Coils 5-1/2
Maximum Locking Torque (In/Lb) 60
Mininum Break Away Torque (oz-in) 6.50
Thread Standard UNF
Material Grade 304
$1.74
