Heli-Coil - Single Insert, 1/4-20 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5-3/4 Free Coils, 3/8 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply

Heli-Coil - Single Insert, 1/4-20 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5-3/4 Free Coils, 3/8 Inch Overall Length, 0.31 to 0.33 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade


Item #: 00063065
Brand: Heli-Coil
Model #: A3585-4CN375
Exact Tooling IR#: 04

Product Specifications
Thread Size 1/4-20
Overall Insert Length (Decimal Inch) 0.3750
Tang Tangless
Length to Diameter Ratio 1-1/2D
Number of Inserts 1
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.3100
Maximum Outside Diameter (Decimal Inch) 0.3300
Finish/Coating Bright
Number of Free Coils 5-3/4
Maximum Locking Torque (In/Lb) 30
Minimum Break Away Torque (In/Lb) 4.50
Thread Standard UNC
Material Grade 304
$1.68
