![Heli-Coil - Single Insert, #10-32 UNF, 3D, Stainless Steel Screw Locking Insert - 14-7/8 Free Coils, 0.57 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0006299-23_1024x1024.jpg?v=1586838262)
Heli-Coil - Single Insert, #10-32 UNF, 3D, Stainless Steel Screw Locking Insert - 14-7/8 Free Coils, 0.57 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00062992
Brand: Heli-Coil
Model #: A3591-3CN570
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #10-32 |
Overall Insert Length (Decimal Inch) | 0.5700 |
Tang | Tangless |
Length to Diameter Ratio | 3D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2360 |
Maximum Outside Diameter (Decimal Inch) | 0.2560 |
Finish/Coating | Bright |
Number of Free Coils | 14-7/8 |
Maximum Locking Torque (In/Lb) | 13 |
Mininum Break Away Torque (oz-in) | 2.00 |
Thread Standard | UNF |
Material Grade | 304 |
