Heli-Coil - Single Insert, #10-24 UNC, 2D, Stainless Steel Screw Locking Insert - 7-1/8 Free Coils, 0.38 Inch Overall Length, 0.244 to 0.259 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply

Heli-Coil - Single Insert, #10-24 UNC, 2D, Stainless Steel Screw Locking Insert - 7-1/8 Free Coils, 0.38 Inch Overall Length, 0.244 to 0.259 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade


Item #: 00062927
Brand: Heli-Coil
Model #: A3585-3CN380
Exact Tooling IR#: 04

Product Specifications
Thread Size #10-24
Overall Insert Length (Decimal Inch) 0.3800
Tang Tangless
Length to Diameter Ratio 2D
Number of Inserts 1
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.2440
Maximum Outside Diameter (Decimal Inch) 0.2590
Finish/Coating Bright
Number of Free Coils 7-1/8
Maximum Locking Torque (In/Lb) 13
Minimum Break Away Torque (In/Lb) 2.00
Thread Standard UNC
Material Grade 304
$1.82
