![Heli-Coil - Single Insert, #10-24 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5 Free Coils, 0.285 Inch Overall Length, 0.244 to 0.259 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/0006291-23_1024x1024.jpg?v=1586858627)
Heli-Coil - Single Insert, #10-24 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5 Free Coils, 0.285 Inch Overall Length, 0.244 to 0.259 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00062919
Brand: Heli-Coil
Model #: A3585-3CN285
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #10-24 |
Overall Insert Length (Decimal Inch) | 0.2850 |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2440 |
Maximum Outside Diameter (Decimal Inch) | 0.2590 |
Finish/Coating | Bright |
Number of Free Coils | 5 |
Maximum Locking Torque (In/Lb) | 13 |
Minimum Break Away Torque (In/Lb) | 2.00 |
Thread Standard | UNC |
Material Grade | 304 |
